BE302022(EVP00156)
ISO1 5/2 Way/Double Coil
SHARE
Model: BE30202 (Double)
The 5/2 solenoid valve can be used in linear motion guide double acting cylinder, the flow rate and with high reliability. You can make the most complex automation becomes more desirable.
Performance:
- Easily interchangeable solenoid
- High Flow
- Can be mounted on each of the 5599/1 ISO base
| Fluid | Filtered air lubricated or lubricated air |
|---|---|
| Connector (Connections) | (2)(4) =1/4" (1)(3)(5) =3/8" |
| Traffic | 1200 NI/min (6bar) |
| Working pressure | 2~10bar |
| Ambient temperature range | -10~60°C |
| Body material | Aluminum |
| Seal Material | HNBR |
| Explosion levels (including connectors) | IP65 (DIN40050) |
| Weight (excluding connectors) | 0.390kg |
